Compressed Air Hose 40bar
softwall hose for compressed air with light traces of oil mist, normally used for heavy duty applications in road construction sites, quarries and mines.
Tube: black, smooth, SBR rubber, oil mist resistant.
Reinforcement: High tensile steel wire.
Cover: black, smooth, (wrapped finish) long lasting EPDM rubber, weathering and ozone resistant.
Temperature: from -30°C (-22°F) to +70°C (+158°F).
Inside Diameter | Outside Diameter | Working Pressure | Burst Pressure | Nominal Weight | |||||
Mm | inch | Mm | inch | Bar | psi | Bar | psi | kg/m | lbs/ft |
13 | 1/2 | 23 | 0.90 | 40 | 600 | 160 | 2320 | 0.64 | 0.44 |
19 | 3/4 | 30 | 1,18 | 40 | 600 | 160 | 2320 | 0,69 | 0,37 |
25 | 1 | 39 | 1,54 | 40 | 600 | 160 | 2320 | 0,90 | 0,60 |
32 | 1-1/4 | 48 | 1,89 | 40 | 600 | 160 | 2320 | 1,27 | 0,86 |
38 | 1-1/2 | 54,5 | 2,15 | 40 | 600 | 160 | 2320 | 1,52 | 1,02 |
51 | 2 | 70 | 2,76 | 40 | 600 | 160 | 2320 | 2,30 | 1,54 |
63,5 | 2-1/2 | 81,5 | 3,21 | 40 | 600 | 160 | 2320 | 2,60 | 1,75 |
76 | 3 | 96 | 3,78 | 40 | 600 | 160 | 2320 | 3,34 | 2,24 |
102 | 4 | 127 | 5,00 | 25 | 362 | 75 | 1087 | 5,01 | 3,37 |
